Description

Body: Heavy duty steel construction, Stainless steel clading at front & enamel Painted steel back & top & sides.‎
Steel floor surface diameter 1000 mm.‎
Fire clay chamber, spherical shape maximum height ‎‎500mm (Model BSC).‎
Thermal Painted steel chamber, spherical shape maximum ‎height 500mm (Model BSS).‎
Painted steel stand, constructed from painted steel tubes ‎‎50‎‏×‏‎50.‎
Control: shut-off gas valve.
Available up-on request: Rotary system for floor surface ‎‎(1.1 k.w/380V/3ph/50 HZ).‎

MODEL                                                                            Dimensions (mm)                    Gas Power(K.W)gas

MASRIA – Venice IG “BSC”
Single Deck – Gas balady Oven, Clay
Chamber, steel Round floor surface.                            1200x 1400 x1800                                   11.8

MASRIA – Venice IG “BSS”
Single Deck – Gas balady Oven, thermal steel
Chamber, steel Round floor surface.                             1200x 1400x 1800                                     11.8
